Configuring Layer 2 Interoperation Service Ports on OLT

It is extremely important for those who have worked in an ISP and require networking between two offices.

• huawei(config)#vlan 300 smart

• huawei(config)#port vlan 300 0/19 0

• huawei(config)#service-port 301 vlan 300 gpon 0/3/1 ont 1 gemport 12 multi-service user-vlan 300
• user-vlan 300

• huawei(config)#service-port 302 vlan 300 gpon 0/4/1 ont 2 gemport 12 multi-service user-vlan 300

• user-vlan 300

• huawei(config)#vlan service-profile profile-id 1

• huawei(config-vlan-srvprof-1)#user-bridging enable //Mandatory huawei

• (config-vlan-srvprof-1)#

• huawei(config-vlan-srvprof-1)#bpdu tunnel enable

• huawei(config-vlan-srvprof-1)#ospf tunnel enable

• huawei(config-vlan-srvprof-1)#rip tunnel enable

• huawei(config-vlan-srvprof-1)#vtp-cdp tunnel enable

• huawei(config-vlan-srvprof-1)#commit

• huawei(config-vlan-srvprof-1)#quit

• huawei(config)#vlan bind service-profile 300 profile-id 1

#networking between 2 ont in huawei olt
#l2networking
